Ubiquiti PowerBeam 5AC-500 (PBE-5AC-500)

Using airMAX ac technology, the NBE-5AC-500 supports up to 450+ Mbps real TCP/IP throughput. It launches with PtP functionality, and a client mode feature will be added with a future firmware upgrade. The PBE-5AC-500 also includes a protective radome to shield the radio from the elements. Ubiquiti's InnerFeed technology integrates the radio into the feedhorn of an antenna, so there is no need for cables to connect the radio to the antenna. This improves performance because it eliminates cable losses. The form factor of the Ubiquiti NanoBeam features the highest gain for its size. The PowerBeam?s excellent beam directivity provides the best performance in high-noise environments. The NanoBeam NBE-5AC-500 includes a protective radome to shield the radio from the elements.

Main features

• High capacity Point-to-Point bridge
• 802.11ac support - up to 450Mbps of real throughput
• Protective radome included
• Innerfeed integrated feeder Technical specification

• Processor Specs	Atheros MIPS 74Kc, 560 MHz
  Memory	128 MB DDR2, 8 MB Flash
  Networking Interface	10/100/1000 Ethernet Port
  Wireless Approvals	FCC, IC, CE
  RoHS Compliance	Yes

  Dimensions
  Radome Excluded	520 x 520 x 308 mm (20.47 x 20.47 x 12.13 in)
  Radome Included	525 x 525 x 315 mm (20.67 x 20.67 x 12.40 in)
  Weight
  Radome Excluded	2.35 kg (5.18 lb)
  Radome Included	3.15 kg (6.95 lb)
  Power Supply	24V, 0.5A Gigabit PoE
  Power Method	Passive PoE (Pairs 4, 5+; 7, 8 Return)
  Max. Power Consumption	8.5W
  Max TX power	27 dBm
  Operating Frequency
  Worldwide	5150 - 5875 MHz
  USA	5725 - 5850 MHz
  Wind Loading	419.6 N @ 200 km/h (94.33 lbf @ 125 mph)
  Wind Survivability	200 km/h (125 mph)
  LEDs	Power, (1) LAN, (4) WLAN Signal Strength LEDs Software-Adjustable to Correspond to Custom RSSI Levels
  Channel Sizes	5/8/10/20/30/40 MHz
  Polarization	Dual Linear
  Enclosure	Outdoor UV Stabilized Plastic
  Mounting	Pole-Mount Kit Included
  ESD/EMP Protection	Air: ? 24 kV, Contact: ? 24 kV
  Operating Temperature	-40 to 70° C (-40 to 158° F)
  Operating Humidity	5 to 95% Non-Condensing
  Salt Fog Test	IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5
  Vibration Test	IEC 68-2-6
  Temperature Shock Test	IEC 68-2-14
  UV Test	IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4
  Wind-Driven Rain Test	ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
